PA66-GF30

PA66 GF30

PA66 GF30 is a 30 % glass fiber-reinforced PA 66. It demonstrates outstanding mechanical properties such as higher strength, rigidity, creep strength, and dimensional stability PA66 GF offers excellent friction and wear performances. This is a very special grade for automotive, electrical, and industrial applications.

Benefits of PA66 GF30 Include:

• Very high stiffness
• Resistant to many oils, greases, and fuels
• Good wear properties
• Very high strength
• High dimensional stability
• Good weldable and bondable
• Good heat deflection temperature of about 220C @1.8 MPa

INDUSTRIES

• Mechanical engineering
• Aircraft and aerospace technology
• Automotive industry

Filament Specifications:

• 1.75mm +/- 0.05mm in diameter

Recommended Print Settings:

• Extruder Temps:  265 – 275°C
• Bed Temps:  125 – 130°C
• Bed Prep:  Rough Borosilicate Glass with PVP gluestick, or High temp carbon fiber sheet plus PVP glue stick, we also recommend the Vision Miner Nano Polymer
• Nozzle: We strongly recommend a 0.4mm orifice or larger using one of our Carbide nozzles
• Drying Instructions:   Please dry @100-105°C for 12-24 hours, for the first dry its recommended to dry for at least 24 hours before using, the drying time can be lowered using a vacuum oven, and also storing the filament in a degassing chamber when not in use.
• Enclosure temp (if your printer is equipped):  50 – 80°C
